ABSTRACT The basil leaves were dried different sources of energy at different loading rates. Using hybrid solar drying compared to the conventional source of energy such as fossil and

propane. Drying parameters were studied. Also, product quality was assessed under study treatments. The results indicated that the higher accumulated weight loss of basil leaves (75.56%)

were obtained at 25 kg m−2 loading rate and solar drying system. The highest rate of the decrease in moisture content of basil leaves was happened at the 45 kg m−2 loading rates. Meanwhile,

the lowest rate of the decrease in moisture content of basil leaves was found at 15 kg m−2 loading rates. The highest drying rate of basil leaves (219.54 gwater kg−1 h−1) was obtained at the

lowest essential oil yield occurred for diesel dryer. The highest value of volatile compounds with found for solar dryer. The total costs for basil drying were 19.73, 26.70 and 23.93 LE h−1

for solar, diesel and propane dryers, respectively. Also, the total costs of basil drying were 8.77, 13.15 and 12.27 LE kg−1 dried for solar, diesel and propane dryers, respectively.

SIMILAR CONTENT BEING VIEWED BY OTHERS EFFECT OF DRYING SYSTEM, LAYER THICKNESS AND DRYING TEMPERATURE ON THE DRYING PARAMETERS, PRODUCT QUALITY, ENERGY CONSUMPTION AND COST OF THE MARJORAM

LEAVES Article Open access 26 February 2024 ASSESSMENT OF A LPG HYBRID SOLAR DRYER ASSISTED WITH SMART AIR CIRCULATION SYSTEM FOR DRYING BASIL LEAVES Article Open access 13 October 2024

DESIGN AND FABRICATION OF BOX-TYPE PASSIVE SOLAR DRYER (BTPSD) WITH THERMAL INSULATION MATERIAL FOR VALORIZING BIOMASS AND NEUTRAL LIPIDS OF MARINE _CHLORELLA VULGARIS_ FOR BIODIESEL

APPLICATION Article Open access 11 April 2022 INTRODUCTION Herbal plants are cultivated in Egypt for local consumption and export as well and it is considered as one of the most important

aromatic plants in Egypt. Its area is about 2121.25 ha, producing about 9031.82 ton/year from green plants and 135.46 ton essential oil1. Basil (_Ocimum basilicum_ L.) belongs to the family

Lamiaceae is an annual, herbaceous, white to purple flowering plant, 20–60 cm tall, that originated in Iran and India2,3 and is considered a main source of essential oil in some countries.

Sweet basil is used for many years to flavour foods, as an ingredient of dental and oral health care products and in fragrances4. Sweet basil leaves are used to improve the taste of foods

like pasta, salads, pizza, meat and often products5,6,7. Drying is the best way of prolonging the shelf-life of products by inhibiting the microorganisms growth, also it preserves aroma,

appearance and nutritional properties. The oxidation reactions which results in drying process of basil may cause reduction in basil volatile content or changing in its nature8,9,10. The

intensity of solar radiation, the temperature, humidity and velocity of the air are continuously changing during sun drying. Therefore, the dried product is affected by drying conditions,

where moisture content and drying rate vary based on drying air temperature and fresh product properties. So that, it is important to take into consideration of these factors or

conditions11. Solar dryers are environmentally friendly and free of pollution and its designs depend on capability, desire and availability of materials resources. The drying of medicinal

and aromatic plants is used extensively and effectively. Investigations in this area provide the optimum conditions for this type of drying all over the world. In Africa, there are many

solar drying designs that can be classified as direct, indirect and hybrid solar dryers12. Using these dryers optimally is the main challenges for drying different kinds of products. Hossain

et al.13 reported that using hybrid solar drying is a good way to dry plants continuously which assure no spoilage or infestation through the night time or off sunshine hours. The use of

solar radiation as the only source of energy is recommended for small-scale dryers but the risk of spoilage of big quantities of crops due to bad weather is exist14,15. If large scale solar

dryers are used for commercial purposes, it is strongly recommended to use artificial dryers or hybrid solar dryers. A huge advantage of solar dryers is the fact that different types of

fruits and vegetables can be dried. The quality of products dried in this way is excellent, due to the fact that the food is not in direct sunlight (cabinet or in-house dryer), and due to a

shorter drying process-up to a 0.3 of the time in as compared to normal sun drying16. The process of solar drying of food continuously by supplementing heat during the night time or low

radiation times is very important to avoid the spoilage by microbial the solar dryers performance by adding heat during low radiation times could increase the drying efficiency and keep the

product quality. To keep the required drying temperature, storage and supplementary heat sources are assessed17,18,19. Food drying is one of the most extensive processes in energy usage

which consumes from 12 to 25% of the total energy of the industrial processing. Conventional energy caused many problems such as pollution and greenhouse gas emission, so, seeking

alternative source of energy such as solar energy will reduce the pollution, keep the quality and reduce the cost of drying process. Also, the loading rater of drying trays is one of the

main affecting the drying efficiency and product quality, therefore, the main aim of this study is to study the possibility of using solar energy in drying and compare it with conventional

types of energy under different loading rates and investigate there effect on the drying parameters of basil leaves. MATERIALS AND METHODS The experiment was conducted out at the Agri. and

Bio-Systems Eng. Dept., Fac. of Agri. Moshtohor, Benha Univ., Egypt (latitude 30° 21′ N and 31° 13′ E), during the period of June and July, 2020. The ambient air temperature ranged from 29.2

to 35.4 °C, the relative humidity ranged from 39 to 71% and solar radiation ranged from 343.6 to 965.7 kJ m−2 day−1. MATERIALS Fresh basil plants that used in the experiment were obtained

from the Experimental Station of the Agriculture College, Benha University which is the same place that conducted the experiment at it. Basil (_Ocimum basilicum_ L.) belongs to the family

Lamiaceae is an annual, herbaceous, white to purple flowering plant, 20–60 cm tall, that originated in Iran and India and has become a major essential oil cultured commercially in some

countries. Sweet basil is a popular culinary herb and its essential oil has been used for many years to flavour foods, as an ingredient of dental and oral health care products and in

fragrances (Fig. 1). DRYING SYSTEMS DESCRIPTION A hybrid type of solar drying system was used in this study. This system used three types of energy sources, namely, solar collector,

collectors plus supplementary diesel fuel and supplementary propane gas fuel. Figure 2 shows the solar drying system description. The system consists of solar collector, drying chamber,

trays, blower and burner. The features of these components could be described as follows: * The solar collector The solar collector consists of three major components, namely: The glass

cover has dimensions of 4.0 m long, 1.0 m width and 5.5 mm thickness. The cover is fixed on a wooden frame with a thickness of 10 cm. It is divided into two lanes, 50 cm wide each. The

absorber plate is made from corrugated black aluminum plate. The insulation is a thermal wool with a 5.0 cm thickness as shown in Fig. 3. * The drying chamber The drying chamber has a length

of 1.0 m, width of 0.75 m and height of 1.0 m. It is made of galvanized steel (5 mm thickness). The inner surface of drying chamber is covered an insulated materials to reduce heat loss

from the walls as shown in Fig. 4. * The drying trays The trays are made of stainless steel and have a length of 0.90 m, width of 0.65 m and height of 0.25 m. They have perforated bottom

which allows heated air to pass through products. * Air blower Two air blowers were used to force and re-circulate the drying air to the drying chamber (Model C.C.P. Parma—Flow Rate 6.6 m3

h−1—RPM 2800—Power 150 W, 220 V 50 Hz, Italy). * The burner The dryer uses a chamber burner system in which heat is being produced. The burner incorporates switches with a sparking mechanism

that ignites the fuel when it is fed from the fuel bottle. The system has two types of fuel, propane gas fuel bottle and tank of providing diesel fuel. * Control units The control unit is

used to control air drying temperature and air recirculation rate. It is consists of data logger and two control units. The data logger. First control unit is used to control of gates and

directions of airflow and second is used to control the fuel feeding rate to the burner. * Air flow directions control gates The system contains seven gates to control the direct of air flow

as follows: * 1. Gate (1) from outlet of dryer chamber to inlet of solar collector. * 2. Gate (2) from outlet of solar collector to inlet of dryer cabinet. * 3. Gate (3) from outlet of

dryer cabinet to inlet of gas burner. * 4. Gate (4) from out area (fresh air) to inlet of solar collector. * 5. Gate (5) from outlet of dryer cabinet to out area. * 6. Gate (6) from solar

collector to inlet of gas burner. * 7. Gate (7) from outlet of burner to inlet of dryer cabinet. The gates were controlled according to Table 1. METHODS Basil was inspected, sorted and

cleaned by removing undesired stems and any waste materials as shown in the process flow chart (Fig. 5). All methods were carried out in accordance to the guidelines and regulations of Benha

University. The optimum conditions of basil drying are 60 °C and 10% relative humidity. EXPERIMENTAL PROCEDURES Experiments were divided into two parts: First part was devoted to determine

the optimum loading rate of basil leaves to ensure high drying quality and performance. This could be achieved by four batch loads (15, 25, 35 and 45 kg m−2). Second part was devoted to

determine the energy required for basil drying from different sources of heat. This could be achieved by using three sources of energy (solar energy, propane and diesel fuels). Weight loss

was determined by electric digital balance (Model HG—5000—Range 0–5000 g ± 0.01 g, Japan) hourly for solar and hybrid solar drying methods. Temperature and relative humidity were recorded by

using a HOBO Data Logger (Model HOBO U12 Temp/RH/Light—Range − 20 to 70 °C and 5 to 95% RH, USA) every hour. Fuel consumption will be recorded for both diesel and propane fuel sources by

weighing the quantity of fuel consumed during drying. PERFORMANCE ANALYSIS Performance analysis was determined by calculating the moisture content changes, drying rate and drying efficiency

as well as energy consumption. * Moisture content Moisture content (MC) of the fresh and dried basil leaves was obtained by using oven drying methods according to20, where samples were

weighed fresh and weighed dried when kept at 105 °C for 24 h or constant weight using the following equation: $$ M{\text{C}} = \frac{{{\text{M}}_{{{\text{wet}}}} - M_{dry}

}}{{{\text{M}}_{{{\text{dry}}}} }} \times {100,} $$ (1) where: MC is the moisture content, % d.b. Mwet is the wet mass of samples, g. Mdry is the dry mass of samples, g. * Drying rate The

drying rate (DR) of basil was determined as follows according to14: $$ DR = \frac{{{\text{M}}_{{{\text{t}} + {\text{dt}}}} - M_{t} }}{{{\text{dt}}}} \, $$ (2) where DR is the drying rate,

(kgwater/kgdry base.h). Mt is the moisture content at any time t, % d.b. Mt+dt is the moisture content at t + dt, % d.b. THE QUALITY OF DRIED PRODUCT * Total chlorophyll content

Spectrophotometric method according to21 was used to determine the chlorophyll (a) and (b) in fresh and dried peppermint leaves as follow: about 500 mg of fresh and 100 mg of dried samples

were collected from all the treatments. Samples with 500 mg weight of fresh basil and 100 g of dried basil were taken from each treatment. Acetone (80%) was added to sample at the rate of 3

ml and then ground using a pestle to extract chlorophyll pigments. Centrifugal tube was used to clarify the samples for 3 min. The clarified sample was dried into volumetric flask and the

volume was made up known volume with acetone 80%. The absorbance values were determined at 663 to 644 nm, against a blank of acetone 80%. Chlorophyll (a), chlorophyll (b) and total

chlorophyll content were determineded using Eqs. (3, 4 and 5) and expressed in mg/g dry weight. $$chl, a= \left[(12.25{A}_{663}-2.79{A}_{644}\times \frac{V}{W\times 1000\times a})\times

\frac{100}{100-M}\right]$$ (3) $$chl,b= \left[(21.50{A}_{644}-5.10{A}_{663}\times \frac{V}{W\times 1000\times a})\times \frac{100}{100-M}\right]$$ (4) $$ {\text{Total}}\,{\text{chlorophyll

}} = {\text{ chl}}.\,{\text{a }} + {\text{ chl}}.\,{\text{b}} $$ (5) where: A is absorbance at specific wavelengths, (644 and 663 nm). V is final volume of chlorophyll extract, (ml). W is

weight of the sample, (g). a is path length of light, (1 cm). * Color analysis Minolta (CR-400) chromameter (Japan) was used to determine the colors of both fresh and dried spearmint plants.

The results in numeric values for three chromatic scales (L*, a*, b*), where L* is the brightness ranging from no reflection for black (L* = 0) to perfect diffuse reflection for white (L* =

 100). The value "a*" is the redness ranging from negative values for green to positive values for red. The value "b*” is the yellowness ranging from negative values for blue

and positive values for yellow. The color at the grid origin (a* = 0 and b* = 0) is achromatic (gray) as described by22. A special white plate was used to calibrate the chromameter. Three

replicates were taken. The color difference was estimated by Eq. (6): $$\Delta E= \sqrt{{({L}_{i}^{*}-{L}_{0}^{*})}^{2}+({a}_{i}^{*}}-{{a}_{0}^{*})}^{2}+({b}_{i}^{*}-{{b}_{0}^{*})}^{2}$$ (6)

where ΔE is the color difference, Li* and L0* are brightness values for dried and fresh plants, respectively, ai* and a0* are greenness-redness values for dried and fresh plants,

respectively, and bi* and b0* are blueness-yellowuess values for driod and fresh plants, respectively. * Extraction of essential oil Steam distillation method was used to determine the

essential oil from fresh and dried spearmint leaves for 3 h as described by23. Spearmint essential oil of fresh and dried sample. The essential oils were dried oven anhydrous sodium sulphate

and stored at -18 °C, till analysis. * Drying efficiency The drying efficiency was calculated by Eq. (7) according to24: $$ \eta =

\frac{{Net\,{\text{energy}}}}{{{\text{Total}}\,{\text{consumption}}\,{\text{energy }}}} $$ (7) $$ Net\,{\text{energy}} = m_{w} {\text{I}}_{{\text{v}}} $$ (8) $$ {\text{ m}}_{{\text{w}}} =

m_{a} \left( {W_{o} - W_{a} } \right) $$ (9) where mw is the evaporation rate, kg s−1. Iv is the evaporative latent heat, kJ kg−1. ma is the mass airflow rate in the dryer, kg s−1. Wo is the

dryer outlet absolute humidity when sensible heat is produced, kg kg−1. Wa is the inlet absolute humidity in drying chamber, kg kg−1. Total consumption rate was calculated for each source

of energy as (for diesel 44,000 kJ kg−1, for propane 46,350 kJ kg−1). * Chromatographic analyses DsChrom 6200 Gas Chromatograph equipped with a flame ionization detector for separation of

volatile oil constituents was used to determine the volatile oil. The chromatograph apparatus was fitted with capillary column DB-WAX 122-7032 Polysillphenylene-siloxane 30 m × 0.25 mm ID × 

0.25 µm film. Temperature program ramp increase with a rate of 13 °C/min and 330 ml/min for air. Detector and injector temperature were 280 °C and 250 °C, respectively. The obtained

chromatogram and report of GC analysis for each sample were analyzed to calculate the percentage of main components of volatile oil7. COST CALCULATION FOR THE DRYING BASIL The costs were

calculated according to25. Table 2 shows inputs of drying cost components for three dryers operate by different energy sources (solar, diesel and propane energies) for basil drying.

STATISTICAL ANALYSIS The data were subjected to analysis using statistical package SPSS version 21 in which one way ANOVA and Duncan Multiple Range Test (DMRT) were performed at significance

level of (p < 0.05) at 95% confidence limit to know the significant differences between the treatment means for different parameters. RESULTS AND DISCUSSION WEIGHT LOSS Figure 6 shows

the accumulated weight loss of basil leaves that dried at different loading rates (15, 25, 35 and 45 kg m−2). The results indicate that the accumulated weight loss of basil leaves increases

with increasing drying period. It could be seen that the accumulated weight loss of basil leaves significantly increased from 27.29 to 75.03%, when the drying period increased from 1 to 24

h, respectively, at 15 kg m−2 loading rate. At 25 kg m−2 loading rate, the accumulated weight loss of basil leaves significantly increased from 21.45 to 75.56%, when the drying period

increased from 1 to 42 h, respectively. At 35 kg m−2 loading rate, the accumulated weight loss of basil leaves significantly increased from 16.74 to 74.91%, when the drying period increased

from 1 to 46 h, respectively and at 25 kg m−2 loading rate, the accumulated weight loss of basil leaves significantly increased from 12.92 to 76.12%, when the drying period increased from 1

to 52 h, respectively. These results agreed with those obtained by26. The results showed that increasing the batch load in a drying chamber, the temperature was decreased. This is due to

increasing the evaporation from the plant with increasing load leading to decreasing the dryer temperature and bulk temperature of basil leaves. Drying batch loading rate 15 kg m−2 basil

leaves consumed 24 h for drying, while 25, 35 and 45 kg m−2 consumed 42, 46 and 52 h, respectively, for drying. These results agreed with those obtained by27. Also, this is consistent with28

who found that the required drying time increases with increasing surface load and small size herbs without stem need low drying time. The results indicate that the accumulated weight loss

of basil leaves decreases with increasing loading rate of basil. It could be seen that, when the loading rate increased from 15 to 45 kg m−2, the accumulated weight loss of basil leaves

significantly decreased from 27.29 to 12.92%, respectively, after1 hour operated for solar dryer. Also, it significantly decreased from 75.03 to 56.11%, when the loading rate increased from

15 to 45 kg m−2, respectively, after 24 h operated for solar dryer. The results also indicate that the shorter drying period (24 h) was occurred at the 15 kg m−2 loading rate. Meanwhile, the

longer drying period (52 h) was occurred at the 45 kg m−2 loading rate. The results show the highest rate of weight loss was occurred at the first hour. It could be seen that the weight

losses were 27.29, 21.45, 16.74 and 12.92% at 15, 25, 35 and 45 kg m−2 loading rate, respectively. Multiple regression analysis was carried out to obtain a relationship between the

accumulated weight loss as dependent variable and different both of loading rate and experimental period as independent variables. The best fit for this relationship is presented in the

following equation:- $$ WL = 51.60 - 0.62LR + 1.49T\quad {\text{R}}^{{2}} = 0.95, $$ (10) where WL is the accumulated weight loss, %. LR is the loading rate of basil, kg m−2. T is the

experimental period, h. This equation could be applied in the range of 15–45 kg m−2 loading rate and from 1 to 24 h of experimental period. Figure 7 shows the accumulated weight loss of

basil leaves that dried under different energy sources (solar, propane and diesel energies). The results indicate that the accumulated weight loss of basil leaves increases with increasing

drying period. It could be seen that the accumulated weight loss of basil leaves significantly increased from 21.45 to 75.56%, when the drying period increased from 1 to 42 h, respectively,

for solar dryer. For diesel dryer, the accumulated weight loss of basil leaves significantly increased from 52.19 to 77.46%, when the drying period increased from 1 to 4 h, respectively. For

propane dryer, the accumulated weight loss of basil leaves significantly increased from 47.35 to 79.39%, when the drying period increased from 1 to 4.6 h, respectively. The results also

indicate that the highest rate of weight loss was occurred at the first hour. It could be seen that the weight losses were 21.45, 52.19 and 47.35% for solar, diesel and propane dryers,

respectively. Regression analysis was aimed out to find a relation between the accumulated weight loss and types for different energy sources and the most appropriate forms were as follows:

$$ {\text{Diesel}}\,{\text{Dryer}}\,{\text{WL }} = { 8}.{44 } + { 48}.{95}\,{\text{ln}}\,{\text{T}}\,{\text{R}}^{{2}} = \, 0.{916} $$ (11) $$ {\text{Propane}}\,{\text{Dryer}}\,{\text{WL }} =

{ 8}.{57 } + { 43}.{81}\,{\text{ln}}\,{\text{T}}\,{\text{R}}^{{2}} = \, 0.{937} $$ (12) $$ {\text{Solar}}\,{\text{Dryer}}\,{\text{WL }} = \, 0.{49 } + {

28}.{34}\,{\text{ln}}\,{\text{T}}\,{\text{R}}^{{2}} = \, 0.{988} $$ (13) MOISTURE CONTENT Figure 8 shows the moisture content of basil leaves that dried at different loading rates (15, 25,

35 and 45 kg m−2) during experimental period. The results indicate that the moisture content of basil leaves decreases with increasing drying period for all treatments. It could be seen that

the moisture content of basil leaves significantly decreased from 443.84 to 12.67% d.b., when the drying period increased from 1 to 24 h at 15 kg m−2 loading rate. At 25 kg m−2 loading

rate, the moisture content of basil leaves significantly decreased from 479.74 to 13.02% d.b., when the drying period increased from 1 to 42 h. At 35 kg m−2 loading rate, the moisture

content of basil leaves significantly decreased from 510.73 to 13.55% d.b., when the drying period increased from 1 to 46 h. 45 kg m−2 loading rate, the moisture content of basil leaves

significantly decreased from 519.87 to 11.97% d.b., when the drying period increased from 1 to 52 h. These results agreed with those obtained by11,29,30. The drying temperatures affected

both time of drying and final moisture content. The higher drying temperature with the shorter total drying time and the lower final moisture content of the dried basil leaves. This could be

due to the vaporization of surface moisture from the material which became more efficient upon contact with more heat31,32. The results indicate that the moisture content of basil leaves

increases with increasing loading rate. It could be seen that, when the loading rate increased from 15 to 45 kg m−2, the moisture content of basil leaves significantly increased from 443.84

to 519.87% d.b., respectively, after 1 h operated for solar dryer. Also, it significantly increased from 12.67 to 43.68% d.b., when the loading rate increased from 15 to 45 kg m−2,

respectively, after 24 h operated for solar dryer. The results indicate that the highest rate of the decrease in moisture content of basil leaves (97.70%) was happened at the 45 kg m−2

loading rate. Meanwhile, the lowest rate of the decrease in moisture content of basil leaves (97.14%) was found at 15 kg m−2 loading rate. The trend of these results agreed with those

obtained by33. Multiple regression analysis was carried out to obtain a relationship between the moisture content as dependent variable and different both of loading rate and experimental

period as independent variables. The best fit for this relationship is presented in the following equation:- $$ MC = 170.31 + 3.56LR - 13.31T\quad {\text{R}}^{{2}} = 0.87 \, $$ (14) where MC

is the moisture content, %. This equation could be applied in the range of 15 to 45 kg m−2 loading rate and from 1 to 24 h of experimental period. DRYING RATE Figure 9 shows the drying rate

of basil leaves that dried at different loading rates (15, 25, 35 and 45 kg m−2) during experimental period. The results indicate that the drying rate of basil leaves decreases with

increasing drying period for all treatments. It could be seen that the drying rate of basil leaves significantly decreased from 219.54 to 0.24 gwater kg−1 h−1, when the drying period

increased from 1 to 24 h at 15 kg m−2 loading rate. At 10 cm thickness basil layer, the drying rate of basil leaves significantly decreased from 177.36 to 0.43 gwater kg−1 h−1, when the

drying period increased from 1 to 42 h. At 25 kg m−2 loading rate, the drying rate of basil leaves significantly decreased from 171.32 to 0.25 gwater kg−1 h−1, when the drying period

increased from 1 to 46 h. At 35 kg m−2 loading rate, the drying rate of basil leaves significantly decreased from 125.31 to 0.31 gwater kg−1 h−1, when the drying period increased from 1 to

52 h. The results also show the relation between moisture content and drying rate for all treatments, the drying rate of basil leaves decreases with increasing moisture content. It could be

seen that, when the moisture content increasing from 443.84 to 519.87% d.b., the drying rate significantly decreased from 219.54 to 125.31 gwater kg−1 h−1 at 15 and 45 kg m−2 loading rate,

respectively, after 1 h of drying time. These results agreed with those obtained by34. The results indicate that the highest rates of the decrease in drying rate of basil leaves were

happened after 1 h of drying period. It could be seen that, the highest rates of the decrease in drying rate of basil leaves were 50.71, 48.82, 47.81 and 46.98% at 15, 25, 35 and 45 kg m−2

loading rate, respectively, after 1 h of drying period. Multiple regression analysis was carried out to obtain a relationship between the drying rate as dependent variable and different both

of loading rate and experimental period as independent variables. The best fit for this relationship is presented in the following equation:- $$ DR = 113.88 - 0.71LR - 6.88T\quad

{\text{R}}^{{2}} = 0.88 $$ (15) where DR is the drying rate, gwater kg−1 h−1. This equation could be applied in the range of 15 to 45 kg m−2 loading rate and from 1 to 24 h of experimental

period. QUALITY OF DRIED BASIL Figure 10 shows the total chlorophyll of basil leaves that dried at different batch loading rates (15, 25, 35 and 45 kg m−2) at the end of experimental period.

The results indicate that the total chlorophyll of basil leaves were 741.1, 745.9, 732.3 and 725.8 for 15, 25, 35 and 45 kg m−2 loading rate, respectively. The results also indicate that

the highest value of total chlorophyll of basil leaves 745.9 was found of 25 kg m−2 batch loading rate. Meanwhile, the lowest value of total chlorophyll of basil leaves 725.8 was found of 45

 kg m−2 batch loading rate. Figure 11 shows the total chlorophyll of basil leaves that dried under different energy sources (solar, propane and diesel energies) at the end of drying period.

The results indicate that the total chlorophyll of basil leaves were 745.9, 715.2 and 703.5 for solar, propane and diesel dryers, respectively. The results also indicate that the highest

value of total chlorophyll of basil leaves 745.9 was found for solar dryer. Meanwhile, the lowest value of total chlorophyll of basil leaves 703.5 was found for diesel dryer. Figure 12 shows

the color of basil leaves that dried at different batch loading rates (15, 25, 35 and 45 kg m−2) at the end of experimental period. The results indicate that the color of basil leaves were

35.98, 36.35, 35.22 and 35.07 for 15, 25, 35 and 45 kg m−2 batch loading rate, respectively. The results also indicate that the highest value of color of basil leaves 36.35 was found of 25

kg m−2 batch loading rate. Meanwhile, the lowest value of color of basil leaves 35.07 was found of 45 kg m−2 batch loading rate. Figure 13 shows the color of basil leaves that dried under

different energy sources (solar, propane and diesel energies) at the end of drying period. The results indicate that the color of basil leaves were 36.35, 32.71 and 31.66 for solar, propane

and diesel dryers, respectively. The results also indicate that the highest value of color of basil leaves 36.35 was found for solar dryer. Meanwhile, the lowest value of color of basil

leaves 31.66 was found for diesel dryer. BASIL ESSENTIAL OIL CONTENT Figure 14 shows the basil essential oil content that dried at different batch loading rates (15, 25, 35 and 45 kg m−2) at

the end of experimental period, extracted by hydrodistillation. The results indicate that the basil essential oil content decreases with increasing batch loading rate. It could be seen that

the basil essential oil content was non-significantly decreased from 2.73 to 2.63%, when the batch loading rate increased from 15 to 45 kg m−2. The results also indicate that the highest

value of basil essential oil content 2.73% was found of 15 and 25 kg m−2 batch loading rate. Meanwhile, the lowest value of basil essential oil content 2.63% was found of 45 kg m−2 batch

loading rate. Figure 15 shows the basil essential oil content that dried under different energy sources (solar, propane and diesel energies) at the end of drying period, extracted by

hydrodistillation. The results indicate that the basil essential oil content were 2.73, 2.39 and 2.02% for solar, propane and diesel dryers, respectively. The results also indicate that the

highest value of basil essential oil content 2.73% was found for solar dryer. Meanwhile, the lowest value of basil essential oil content 2.02% was found for diesel dryer. The highest

essential oil yield obtained for solar dryer, the lowest essential oil yield occurred for diesel dryer. The trend of these results agreed with those obtained by7 whose mentioned that

increasing the drying temperature significantly decreased the essential oil content. Generally, according to35,36,37 essential oil yield of medicinal and aromatic plants is influenced by

drying, whereas depending on the process time and temperature as well as the method, the oil yield could be increased and/or decreased. Furthermore, changes in the oil content are dependent

on the plant species. DRYING EFFICIENCY Figure 16 shows the drying efficiency of basil leaves at different batch loading rates (15, 25, 35 and 45 kg m−2) at the end of experimental period.

The results indicate that the drying efficiency of basil leaves were 35.06, 40.33, 38.52 and 33.98% for 15, 25, 35 and 45 kg m−2 loading rate, respectively. The results also indicate that

the highest value of drying efficiency of basil leaves 40.33% was found of 25 kg m−2 batch loading rate. Meanwhile, the lowest value of total chlorophyll of basil leaves 33.98 was found of

45 kg m−2 batch loading rate. Figure 17 shows the drying efficiency of basil leaves under different energy sources (solar, propane and diesel energies) at the end of drying period. The

results indicate that the drying efficiency of basil leaves were 40.33, 46.15 and 51.07% for solar, propane and diesel dryers, respectively. The results also indicate that the highest value

of the drying efficiency of basil leaves 51.07% was found for propane dryer. Meanwhile, the lowest value of the drying efficiency of basil leaves 40.33% was found for solar dryer. The trend

of these results agreed with those obtained by38 whose found the highest drying efficiency obtained for gas dryer, the lowest the drying efficiency occurred for solar dryer. Also, these

results agreed with those obtained by39. VOLATILE COMPOUNDS OF BASIL Table 3 shows the volatile compounds of basil that dried under different energy sources (solar, propane and diesel

energies) at the end of drying period, extracted by hydrodistillation. A typical chromatogram of volatile composition of dry basil leaves is shown in Fig. 18a–c. The results indicate that

the volatile losses which increased with higher temperature and lower drying time. The best results from a volatile composition point of view were obtained for sample convectively dried in

solar dryer. It could be seen that the α-pinene and β-pinene were 0.62, 0.52 and 0.18 and 6.23, 8.10 and 3.23% for solar, propane and diesel dryers, respectively. The linalool, camphor and

methyl chavicol were 30.85, 36.15 and 35.88, 4.74, 4.48 and 3.04 and 11.54, 8.36 and 7.08% for solar, propane and diesel dryers, respectively. The geraniol, eugenol and β-caryophelliene were

7.88, 5.14 and 8.68, 20.95, 19.14 and 18.40 and 2.99, 2.52 and 2.32% for solar, propane and diesel dryers, respectively. The results also indicate that the highest value of volatile

compounds with found for solar dryer. The trend of these results agreed with those obtained by40 whose found that the volatile composition of basil leaves decreases with increasing the

drying temperature. DRYING COSTS Table 4 shows the fixed, variable, total costs and total costs per kg for the basil drying. It could be seen that the fixed costs were 5.77 LE h−1 for

different dryer (solar, diesel and propane dryers). The variable costs were 13.96, 20.93 and 18.16 LE h−1 for solar, diesel and propane dryers, respectively. The total costs for basil drying

were 19.73, 26.70 and 23.93 LE h - 1 for solar, diesel and propane dryers, respectively. Also, the total costs per kg of basil drying were 8.77, 13.15 and 12.27 LE for solar, diesel and

propane dryers, respectively. The total costs of basil dried in diesel dryer were 1.5 times higher than those basil dried in solar dryer, also the total costs of basil dried in propane dryer

were 1.4 times higher than those basil dried in solar dryer. Besides the solar energy is a clean source of energy and environmental friendly used. It could be noticed that the drying costs

were affected by changing the batch load in the solar dryer, where it varied from 12.98 to 4.78 LE kg−1 when the batch load changed from 15 to 45 kg m−2, respectively. CONCLUSION The

experiment was carried out successively to investigate the effect of different loading rates on the energy required for basil drying with different sources of energy. It is concluded that

the accumulated weight loss of basil leaves increased from 27.29 to 75.03, 21.45 to 75.56, 16.74 to 74.91 and 12.92 to 76.12% at 15, 25, 35 and 45 kg m−2 loading rate of basil, respectively.

The highest rate of the decrease in moisture content of basil leaves (97.70%) was happened at the 45 kg m−2 loading rate of basil. The drying rate of basil leaves ranged from 125.31 to

219.54 gwater kg−1 h−1 for all treatments under study. The highest values of total chlorophyll and color of basil leaves 745.9 and 36.35 were found for solar dryer. The basil essential oil

content was decreased from 2.73 to 2.63%, when the batch loading rate increased from 15 to 45 kg m−2. The highest value of the drying efficiency of basil leaves 51.07% was found for propane

dryer. The total costs for basil drying were 19.73, 26.70 and 23.93 LE h−1 for solar, diesel and propane dryers, respectively. Also, the total costs per kg of basil drying were 8.77, 13.15

and 12.27 LE for solar, diesel and propane dryers, respectively. Besides the solar energy is a clean source of energy and environmental friendly used. The optimum conditions of basil drying

rate, loading rate 25 kg m−2, 60 °C and 10% RH. Which gave higher efficiency and low energy requirements. Using propane saved 58.8% of than energy required from diesel fuel. Further studies

should be carried out on the effect of a recirculation rate on drying efficiency. More studies could be on more different sources of heat. It is worthy to conclude that solar drying reduced

the CO2 gas emission, where basil dried using fuel produced 0.5 kg CO2 for 1 kg dried and using propane fuel produced 0.04 kg CO2 for 1 kg dried product. DATA AVAILABILITY The datasets used

and/or analyzed during the current study available from the corresponding author on reasonable request. REFERENCES * GAEO (General of Agricultural Economics organization)—Ministry of

Agriculture and Land Reclamation. Acreage statistics and vegetable production in the Arab Republic of Egypt (2020) (UNPUBLISHED). * Özcan, M., Arslan, D. & Ünver, A. Effect of drying

methods on the mineral content of basil (_Ocimum basilicum_ L.). _J. Food Process. Eng._ 69, 375–379 (2005). Article  Google Scholar  * Chalchat, J. C. & Özcan, M. M. Comparative

essential oil composition of flowers, leaves and stems of basil (_Ocimum basilicum_ L.) used as herb. _Food Chem._ 110, 501–503 (2008). Article  CAS  PubMed  Google Scholar  * Lachowicz, K.

J. _et al._ The synergistic preservative effects of the essential oils of sweet basil (_Ocimum basilicum_ L.) against acid-tolerant food microflora. _Lett. Appl. Microbiol._ 26, 209–214

(1998). Article  CAS  PubMed  Google Scholar  * Özcan, M. & Chalchat, J. C. Essential oil composition of _Ocimum basilicum_ L. and _Ocinum minimum_ L. in Turkey. _Czechoslovak. J. Food

Sci._ 20(6), 223–228 (2002). Article  Google Scholar  * Sajjadi, S. E. Analysis of the essential oils of two cultivated basil (_Ocimum basilicum_ L.) from Iran. _DARU J. Pharm. Sci._ 14,

128–130 (2006). CAS  Google Scholar  * Ghasemi Pirbalouti, A., Mahdad, E. & Craker, L. Effects of drying methods on qualitative and quantitative properties of essential oil of two basil

landraces. _Food Chem._ 141, 2440–2449 (2013). Article  CAS  PubMed  Google Scholar  * Crivelli, G., Nani, R. C. & Di Cesare, L. F. Influence of processing on the quality of dried herbs.

Atti VI Giornatescientifiche SOI. _Spoleto_ 2, 463–464 (2002). Google Scholar  * Diaz-Maroto, M. C., Pérez-Coello, M. S. & Cabezudo, M. D. Effect of drying method on the volatilities in

bay leaf (_Laurusnobilis_ L.). _J. Agric. Food Chem._ 50, 4520–4524 (2002). Article  PubMed  Google Scholar  * Thamkaew, G., Sjöholm, I. & Galindo, F. G. A review of drying methods for

improving the quality of dried herbs. _Crit. Rev. Food Sci. Nutr._ 61(11), 1763–1786. https://doi.org/10.1080/10408398.2020.1765309 (2021). Article  CAS  PubMed  Google Scholar  * Amer, B.

M. A., Gottschalk, K. & Hossain, M. A. Integrated hybrid solar drying system and its drying kinetics of chamomile. _Renew. Energy_ 121, 539–547 (2018). Article  Google Scholar  * Ndukwu,

M. C., Bennamoun, L. & Abam, F. I. Experience of solar drying in Africa: Presentation of designs, operations, and models. _Food Eng. Rev._ 10, 211–244 (2018). Article  CAS  Google

Scholar  * Hossain, M. A., Amer, B. M. A. & Gottschalk, K. Hybrid solar dryer for quality dried tomato. _Dry. Technol._ 26, 1591–1601 (2008). Article  CAS  Google Scholar  * Fadhel, M.

I., Sopian, K., Daud, W. R. W. & Alghoul, M. A. Performance analysis of solar-assisted chemical heat-pump dryer. _Sol. Energy_ 84, 1920–1928 (2010). Article  ADS  CAS  Google Scholar  *

El-Kashoty, M. M., Khater, E. G., Bahnasawy, A. H. & Nagy, K. S. Effect of temperature and air recirculation rate on the weight losses of mint under hybrid solar drying conditions.

_Misr. J. Agric. Eng._ 37(4), 357–372 (2020). Article  Google Scholar  * Kabeel, A. E., El-Sheekh, M. M. & Masoud, A. A. Performance analysis of direct solar dryer driven by photovoltaic

thermal energy recovery and solar air collector for drying materials and electricity generation. _Heat Transf._ 51, 3573–3585 (2022). Article  Google Scholar  * Hossain, M., Barry-Ryan, C.,

Martin-Diana, A. & Brunton, N. Effect of drying method on the antioxidant capacity of six lamiaceae herbs. _J. Food Chem._ 1, 85–91 (2008). Google Scholar  * Ndukwu, M. C. _et al._

Drying kinetics and thermo-economic analysis of drying hot water blanched ginger rhizomes in a hybrid composite solar dryer with heat exchanger. _Heliyon_ 9, e13606 (2023). Article  PubMed

PubMed Central  Google Scholar  * Onyenwigwe, D. I. _et al._ Mathematical modelling of drying kinetics, economic and environmental analysis of natural convection mix-mode solar and sun

drying of pre-treated potato slices. _Int. J. Ambient Energy_ 44(1), 1721–1732 (2023). Article  CAS  Google Scholar  * ASAE Standard. ASAE 5352.1.moisture measurement. American Society of

Agric. Eng. 2950 Niles Road, St. Joseph, MI 49085-9659 (1984). * Lichtenthaler, H. K. & Buschmann, C. Chlorophylls and carotenoids: Measurement and characterization by UV-VIS

spectroscopy. In _Current Protocols in Food Analytical Chemistry_ (ed Whitaker, J.) F4.3.2–F4.3.8 (Wiley, 2001). * Tarhan, S., Telci, I., Tuncay, M. T. & Polatci, H. Product quality and

energy consumption when drying peppermint by rotary drum dryer. _Ind. Crops Prod._ 32, 420–427 (2010). Article  Google Scholar  * Mkaddem, M. _et al._ Chemical composition and antimicrobial

and antioxidant activities of Mentha (longifolia L. and viridis) essential oil. _J. Food Sci._ 74(7), 358–363 (2009). Article  Google Scholar  * Altobelli, F., Condorí, M., Duran, G. &

Martinez, C. Solar dryer efficiency considering the total drying potential. Application of this potential as a resource indicator in north-western Argentina. _Sol. Energy_ 105, 742–759

(2014). Article  ADS  Google Scholar  * Khater, E. G., Bahnasawy, A. H. & Morsy, O. Evaluation of fish feeder manufactured from local raw materials. _Sci. Rep._ 11(18799), 1–13.

https://doi.org/10.1038/s41598-021-98383-0 (2021). Article  CAS  Google Scholar  * Khater, E. G. & Bahnasawy A. H. Basil drying performance and quality under different drying systems. In

_2nd International Sino-Egyptian Congress on Agriculture, Veterinary Sciences and Engineering (2nd ISEC-AVE), 7–10 October, 2017, Egypt_ (2017). * Morad, M. M., El-Shazly, M. A., Wasfy, K.

I. & El-Maghawry, H. A. M. Thermal analysis and performance evaluation of a solar tunnel greenhouse dryer for drying peppermint plants. _Renew. Energy_ 101, 992–1004 (2017). Article

Google Scholar  * Fatouh, M., Metwally, M. N., Helali, A. B. & Shedid, M. H. Herbs drying using a heat pump dryer. _Energy Convers. Manag._ 47, 2629–2643 (2006). Article  Google Scholar

  * Li, H. & Ramaswamy, H. S. Osmotic dehydration of apple cylinders: I. Conventional batch processing conditions. _Dry. Technol._ 24, 619–630 (2006). Article  CAS  Google Scholar  *

Khater, E. G., Bahnasawy, A. H. & Hamouda, R. M. Dehydration of chamomile flowers under different drying conditions. _J. Food Proc. Technol._ 10(7), 1–7 (2019). Google Scholar  * Doymaz,

I. Air-drying characteristic, effective moisture diffusivity and activation energy of grape leaves. _J. Food Proc. Preserv._ 36(2), 161–168 (2011). Article  Google Scholar  * Abdul Kahar,

A. A., Ong, S. P., Watson, N. J. & Law, C. L. Effect of different drying methods and conditions on drying performance and volatile retention of _Backhousia citriodora_ (lemon myrtle)

leaves. _Int. Food Res. J._ 29(3), 572–581 (2022). Article  CAS  Google Scholar  * Danso-Boateng, E. Effect of drying methods on nutrient quality of Basil (_Ocimum viride_) leaves cultivated

in Ghana. _Int. Food Res. J._ 20(4), 1569–1573 (2013). Google Scholar  * Wang, P. _et al._ Roof solar drying processes for sewage sludge within sandwich-like chamber bed. _Renew. Energy_

136, 1071–1081 (2019). Article  Google Scholar  * Hamrouni Sellami, I. _et al._ Qualitative and quantitative changes in the essential oil of _Laurus nobilis_ L. leaves as affected by

different drying methods. _Food Chem._ 126(2), 691–697. https://doi.org/10.1016/j.foodchem.2010.11.022 (2011). Article  CAS  Google Scholar  * Beigia, M., Torki-Harcheganib, M. & Ghasemi

Pirbaloutic, A. Quantity and chemical composition of essential oil of peppermint (Mentha × piperita L.) leaves under different drying methods. _Int. J. Food Prop._ 21(1), 267–276.

https://doi.org/10.1080/10942912.2018.1453839 (2011). Article  CAS  Google Scholar  * Abd El-Haq, O. M., Khater, E. G., Bahnasawy, A. H. & El-Ghobashy, H. M. Effect of drying systems on

the parameters and quality of dried basil. _Ann. Agric. Sci. Moshtohor._ 58(2), 261–272 (2020). Article  Google Scholar  * Lopez-Vidan, E. C., Mendez-Lagunas, L. L. & Rodriguez-Ramirez,

J. Efficiency of a hybrid solar–gas dryer. _Sol. Energy_ 93, 23–31 (2013). Article  ADS  Google Scholar  * Onyenwigwe, D. I. _et al._ Eco-thermal analysis and response surface optimization

of the drying rate of potato slices in a mix-mode solar dryer. _Iran. J. Sci. Technol. Trans. Mech. Eng._ 47, 1–18. https://doi.org/10.1007/s40997-023-00595-4 (2023). Article  Google Scholar

  * Abd El-Haq, O. M., Khater, E. G., Bahnasawy, A. H. & El-Ghobashy, H. M. Effect of distillation methods on essential oil yield and composition of basil dried by different drying

systems. _Ann. Agric. Sci. Moshtohor._ 58(2), 247–260 (2020). Article  Google Scholar  Download references ACKNOWLEDGEMENTS This work is fully sponsored by the Support and Development of

Scientific Research Center, Benha University. We would also like to show our gratitude to the Arab Academy for Science and Technology and Maritime Transport, Cairo, Egypt. FUNDING Open

access funding provided by The Science, Technology & Innovation Funding Authority (STDF) in cooperation with The Egyptian Knowledge Bank (EKB). This research was supported by the Support

and Development of Scientific Research Center, Benha University, Egypt. We would also like to show our gratitude to the Arab Academy for Science and Technology and Maritime Transport,

Cairo, Egypt. AUTHOR INFORMATION AUTHORS AND AFFILIATIONS * Agricultural and Biosystems Engineering Department, Faculty of Agriculture, Benha University, Moshtohor, P.O. Box 13736, Toukh,

Kalubia, Egypt El-Sayed G. Khater & Adel H. Bahnasawy * Basic and Applied Science Department, College of Engineering and Technology, Arab Academy for Science and Technology and Maritime

Transport (AASTMT), P.O. Box 2033, Cairo, Egypt Wael Abbas & Osama M. Morsy Authors * El-Sayed G. Khater View author publications You can also search for this author inPubMed Google

Scholar * Adel H. Bahnasawy View author publications You can also search for this author inPubMed Google Scholar * Wael Abbas View author publications You can also search for this author

inPubMed Google Scholar * Osama M. Morsy View author publications You can also search for this author inPubMed Google Scholar CONTRIBUTIONS E.-S.K., A.B., W.A. and O.M.: Investigation,

resources, writing—original draft preparation, writing—review and editing. CORRESPONDING AUTHOR Correspondence to El-Sayed G. Khater. ETHICS DECLARATIONS COMPETING INTERESTS The authors

declare no conflict of interest. The funders had no role in the design of the study; in the collection, analyses, or interpretation of data; in the writing of the manuscript, and in the

decision to publish the results. ADDITIONAL INFORMATION PUBLISHER'S NOTE Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional

affiliations. RIGHTS AND PERMISSIONS OPEN ACCESS This article is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution

and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons licence, and indicate if

changes were made. The images or other third party material in this article are included in the article's Creative Commons licence, unless indicated otherwise in a credit line to the

material. If material is not included in the article's Creative Commons licence and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will

need to obtain permission directly from the copyright holder. To view a copy of this licence, visit http://creativecommons.org/licenses/by/4.0/. Reprints and permissions ABOUT THIS ARTICLE

CITE THIS ARTICLE Khater, ES.G., Bahnasawy, A.H., Abbas, W. _et al._ Effect of loading rate and source of energy on the drying parameters of the basil during drying. _Sci Rep_ 13, 14796

(2023). https://doi.org/10.1038/s41598-023-41697-y Download citation * Received: 09 November 2022 * Accepted: 30 August 2023 * Published: 08 September 2023 * DOI:

https://doi.org/10.1038/s41598-023-41697-y SHARE THIS ARTICLE Anyone you share the following link with will be able to read this content: Get shareable link Sorry, a shareable link is not

currently available for this article. Copy to clipboard Provided by the Springer Nature SharedIt content-sharing initiative
